- Camera
- Max. Resolution2688 × 1520
- Sensor Type1/1.8" Progressive Scan GMOS（Global shutter CMOS）
- Min. Illumination
Color: 0.0005 Lux @ (F1.2, AGC ON)
B/W: 0.0001 Lux @ (F1.2, AGC ON)
0 Lux with IR
- Shutter1/30 s to 1/100,000 s
- Day/Night SwitchSupported
- IR Cut Filter
IR cut filter
Blue glass module to reduce ghost phenomenon
- Lens
- Lens Type4mm
- ApertureF1.6
- Focal Length and FoV4 mm, horizontal FoV: 79°, vertical FoV: 43.3°, diagonal FoV: 92°
- Lens MountM16
- lris TypeFixed
- Supplement Light
- Supplement Light TypeIR Light
- Supplement Light Range850nm
- Image
- Main Stream
50 Hz: 50 fps (2688 × 1520(Default), 1920 × 1080, 1280 × 720)
60 Hz: 60 fps (2688 × 1520(Default), 1920 × 1080, 1280 × 720)
- Sub-Stream
50 Hz: 50 fps (1920 × 1080(Default), 1280 × 720, 704 × 576)
60 Hz: 60 fps (1920 × 1080(Default), 1280 × 720, 704 × 576)
- Third Stream
50 Hz: 50 fps (1280 × 720(Default), 704 × 576)
60 Hz: 60 fps (1280 × 720(Default), 704 × 576)
- Image Settings
Saturation: 0 to 100
Brightness: 0 to 100
Contrast: 0 to 100
Gain: 0 to 100
3D DNR: Off, Normal, and Expert modes are selectable.
White balance: White Balance 1 and White Balance 2 are selectable.
- Frame Rate50 fps (P)/60 fps (N)
- Video
- ROI8 regions respectively for main stream and sub-stream, 6 levels for each region.
- Video Compression
Main stream: H.265/H.264/MJPEG,
Sub-stream: H.265/H.264/MJPEG,
- H.264 Type
Low profile
Medium profile
High Profile
- Video Bit Rate32 Kbps to 16 Mbps
- Bit Rate TypeConstant, Variable
- Scalable Video Coding (SVC)H.265 encoding
- Capture Mode
- Trigger TypeVideo Detection, I/O Coil, Radar Mixed Traffic
- Picture TypeScene Picture, Scene Picture + Close-up Picture
- Scene ModeEntrance and Exit Toll Gate, Underground Parking Entrance and Exit
- Capture TypeStrobe Light Mode
- Capture Parameters
- Image FormatJPEG
- Capture Resolution2688 × 1520
- License Plate RecognitionForward, Backward, Bidirection
- LED ControlSupports automatic light control/time control of LEDs
- Smart RecognitionANPR
- Capture Picture OverlayLocation, Capture Time, Plate Number, Capture No., Vehicle Color Vehicle Type
- Entrance and Exit
- Barrier Gate Control ModeBy Camera/Platform/Mixed
- Keep Boom Pole Open for Following VehicleEnable/Disable
- Lock Barrier Gate for Large-Sized VehicleYes
- Barrier Gate StatusNone, Barrier Gate Close In Place, Barrier Gate Open In Place, Remote Control Barrier Gate
- Allowlist and Blocklist
Up to 100,000 allowlist and blocklist totally
Note: Only when the TF card is available, can the function take effect.
- Network
- Network StorageNAS (NFS, SMB/CIFS), auto network replenishment (ANR) together with high-end Hikvision memory card, memory card encryption and health detection are supported.
- ProtocolTCP/IP, ICMP, HTTP, HTTPS, FTP Upload Picture, SRTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, IGMP, QoS, IPv6, UDP, SSL/TLS
- APIOpen Network Video Interface (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK, ISUP, Otap, Guarding Vision Platform
- ClientiVMS-4200, Hik-Connect, Hik-Central
- Web Browser
Plug-in required live view: IE10+ Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari 11+
Local service: Chrome 41.0+, Firefox 30.0+
- SecurityPassword protection, complicated password, HTTPS encryption, watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP OVER HTTPS, Control Timeout Settings, Security Audit Log, TLS 1.2
- Interface
- Trigger Input3-ch triggered inputs
- Trigger Output2-ch alarm output
- Wiegand1-ch, Supported: CardID 26bit, SHA-1 26bit, Hik 34bit, NEWG 72bit
- Alarm Input4-ch
- RS-4851-ch
- RS-2321-ch
- Network Interface1 RJ45 10M/100M self-adaptive Ethernet port
- Memory Card Slot1 TF card slot, up to 512G
- Relay Output4-ch
- Power Output12VDC, max.1A
- Smart Function
- LPR Accuracy
Capture rate ＞ 98%
Vehicle moving direction recognition accuracy ＞ 98.5%
LPR accuracy ＞ 98%
Mistaken capture rate ＜ 2%
European and Russian-Speaking Regions:
LPR accuracy ＞ 98%
Country/Region recognition accuracy ＞ 95%
- ANPR Supported Country/Region
Middle East:
The United Arab Emirates (Abu Dhabi, Ajman, Dubai, Fujairah, Ras Al Khaimah, Sharjah and Umm Al Quwain), Qatar, Iraq, Egypt, Jordan, Kuwait, Saudi Arabia, Pakistan, Oman, Lebanon, Bahrain
Africa:
Nigeria, Kenya, Ivory Coast , South Africa, Tanzania, Mauritius, Morocco, Tunisia, Sierra Leone, Zambia, Ghana, Zimbabwe, Uganda, Angola, Ethiopia, Senegal, Algeria
Asia-Pacific:
Australia, New Zealand, Indonesia, Malaysia, Singapore, South Korea, Thailand, Vietnam, the Philippines, Hong Kong, Macao, Taiwan, Myanmar, India, Mongolia, Cambodia, Laos, Bangladesh, Nepal, Sri Lanka
America:
Canada, Argentina, Chile, Paraguay, Uruguay, El Salvador, Bolivia, Colombia, Brazil, Ecuador, Peru, Mexico, Panama, Costa Rica, Trinidad and Tobago, the Dominican Republic, Guatemala
Europe:
Turkey, Croatia, Slovakia, Czech Republic, Bulgaria, the Republic of North Macedonia, Hungary, Greece, Poland, France, Netherlands, Switzerland, Spain, the UK, Ireland, Germany, Italy, Austria, Israel, Palestinian, Belgium, Luxembourg, Albania, Kosovo, Serbia, Romania, Montenegro, Denmark, Finland, Sweden, Slovenia, Portugal, Malta, Cyprus, Iceland, Liechtenstein, Bosnia and Herzegovina
Russian-Speaking Regions:
Azerbaijan, Belarus, Kazakhstan, Lithuania, Georgia, Estonia, Latvia, Russia, Ukraine, Moldova, Uzbekistan, Kyrgyzstan, Armenia, Turkmenistan, Tajikistan
- Valid Distance1.5 to 12m
- General
- Power Supply24VDC
- Power Consumption72W Max.
- Package Dimensions465 mm × 200 mm × 198 mm (18.31 × 7.87 × 7.80 inch)
- Dimensions195 × 150 × 673 mm (7.68 × 5.91 × 26.5 inch)
- Weight9.1 kg (20.06 lb.)
- Storage Temperature and Humidity
Temperature: -30 °C to 70 °C (- 4°F to 158 °F)
Humidity: 95% (non-condensing)
- Startup and Operating Conditions
Temperature: -30 °C to 65 °C (-22 °F to 149 °F)
Humidity: 95% (non-condensing)
- Language33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
|
